SEETEC 12G238F 23.8 INCH 4K 8K BROADCAST PRODUCTION HDR MONITOR 4X 12G SDI IN OUT 2X HDMI 3840X2160

Professional film and television production monitor The SEETEC 12G238F is a professional film and television production monitor equipped with 4x12G SDI that supports 8K signal input and gives you a native display of 2160p 60.  You can also connect your computer to control the monitor via applications.  The monitor is widely used in pre shooting and post color correction of broadcast, film and television and high end advertising production. Highlights 23.8 inch LCD monitor Ultra high resolution of 3840x2160, Highly accurate 3D LUT Rugged and durable View more details The monitor has a 23.8 inch LCD panel, with an ultra high resolution of 3840x2160, a color depth of up to 10bit and display of 1.07B colors, allowing you to see color performance you've never seen before, and more creation space for color grading. The monitor covers 100% Rec.709 and 98% DCI P3 wide color gamut, with rich colors. And supports ITU R BT.2020, ITU R BT.709, EBU, SMPTE C, Native and other color gamuts, meet photographers' different needs for color gamut. The monitor uses a highly accurate 3D LUT that supports the tetrahedral interpolation algorithm, and the built in Rainbow color management engine ensures that the monitor has accurate color reproduction capabilities. Rugged and durable, easy to dissipate heat The full aluminum alloy frame not only makes the device more sturdy and durable, but also solves the problem of heat dissipation. Flexible and intuitive button operation The monitor can easily switch between sources with one button, custom shortcuts and quickly call up menus to make shooting easier. The backlight button design makes it easier to distinguish the current input signal and shortcut buttons used, easy to use. A new visual experience It comes with 4 x 12G SDI inputs and outputs, supports up to 8K signal input, allows multiple input configurations, 2 x HDMI 2.0 inputs, supports up to 4096x2160p(60/59.94/50/30/29.97/25/24 /23.98) & 3840x2160p(60/50/30/25/24) signal. Matching the refresh rate of 60 frames per second, 4K audio and video transmission can be resolved with only a single cable. Seamless, fast, reliable data communication connection The monitor comes with SFP interface, can place the 12G SFP fiber optic module, which is an essential part of high speed telecommunications and data communications, especially in large network environments, which enables the reception of broadcast quality video data at transmission level through a fiber optical connection. Remote control application. Connect your computer to control the monitor via applications. The RS422 input and output can realize synchronization control of multiple monitors. Real time control of the monitor's signal input source, turn on waveform and other functions. VESA mounting points The monitor is equipped with 100 mm/200 mm two VESA mounting sizes, you can easily hang it on a wall. Flexible mounting for a busy newsroom. Note: the bracket is not included., Model: 12G238F Screensize: 23,8” Brightness: 540 Screen Gamut: 98% DCI P3 SDI Interface: 4 x 12 G SDI (support 8K input) HDMI interface: 2x HDMI 2.0 Other interface: 1 x Type C, 1 x SFP, 1 x LAN, 1 x GPI, RS422 in & out Tally: Front Power: AC+DC 3D LUT: Tetrahedral interpolation, Uses LUT HDR: PQ+HLG EETF: Yes Still image detection: Support Gamma: Gamma 2.0, Gamma 2.2, Gamma 2.4, Gamma 2.6, SMPTE ST 2084(PQ), ITU R BT.2100(HLG), S Log3, Canon Log Camera Log: Sony, Canon, ARRI, DJI Log mode Gamut Comparison: SDR and HDR Images Comparison GamutWarning: Yes Multi view: Quad view, Quadview triple side, Quad triple bottom, PBP, PAP UMD: 3.1, 4.1, 5.0 Waveform, Vector, Histogram: Yes Time Code: Yes 2 year warranty
