BRESSER Mechanical Stage for Stereo Microscopes (95 mm)

The BRESSER Mechanical Stage for Stereo Microscopes allows precise object movement in both the X and Y directions, making accurate positioning easy. Each axis features a vernier scale for added precision.
_x000D_ Thanks to its adjustable movement, the mechanical stage can also be used to create mosaic images when combined with a BRESSER MikroCam (II, SP, SF).
_x000D_
_x000D_ It is designed to replace the standard stage plate on a microscope and is compatible with devices that have a 95 mm stage plate.
_x000D_ The maximum movement range is 165 x 65 mm, depending on the microscope’s size.
_x000D_
_x000D_ With a height of 26 mm above the microscope stage, the mechanical stage slightly reduces the maximum object height.
_x000D_
_x000D_ Compatible with the following devices:
_x000D_
_x000D_

_x000D_
• BRESSER Erudit ICD (5803600)
_x000D_
• BRESSER Advance ICD (5804000)
_x000D_
• BRESSER DST-0745 (5808100)
_x000D_

_x000D_
_x000D_
_x000D_ FEATURES
_x000D_
_x000D_

_x000D_
• Suitable for microscopes with a 95 mm object plate
_x000D_
• Maximum movement range: 165 x 65 mm (depending on the microscope size)
_x000D_
• Coaxial adjustment knobs for smooth operation
_x000D_
• Precision measuring bar with vernier scales on both axes
_x000D_
• Compatible with both reflected and transmitted light microscopy
_x000D_

_x000D_
_x000D_
_x000D_ SCOPE OF DELIVERY
_x000D_
_x000D_

_x000D_
• Mechanical stage with glass plate and two object clamps
_x000D_

_x000D_ _x000D_
