In the microscope's basis, there are a transmitted light LED illuminator (3 W) as well as the power supply and the continuous adjustable dimmer for transmitted light. The trinocular head allows to mount a SLR camera or a USB microscope camera with an optional adapter. The inclination of the eyepiece tubes is 30°. The fluorescence attachment includes a special LED wheel with four different lamps (green, blue, violett, ultraviolett), a filter wheel and a radiation shield. The LED lamps produces the exciting radiation in order to get fluorescence.
_x000D_ Fluorescence microscopy is done e. g. in biology, medicine, microchemistry, geology, semiconductor production and environmental protection. The Science ADL 601F LED is an instrument with an excellent value for money. It has also the other features, which are typical for high-quality microscopes: fourfold objective nosepiece, lengthwise and cross moveable stage, coaxial focusing knobs (concerning fine drive: 200 µm / full turn), adjustment of eye relief, diopter adjustment and the phototube. Optional available, general accessories are the wide field eyepieces (WF10x, WF15x), the dividing eyepiece (WF10x), and dark field condensers (dry and oil).
_x000D_
_x000D_ FEATURES
_x000D_
_x000D_
_x000D_ Fluorescence microscopy is done e. g. in biology, medicine, microchemistry, geology, semiconductor production and environmental protection. The Science ADL 601F LED is an instrument with an excellent value for money. It has also the other features, which are typical for high-quality microscopes: fourfold objective nosepiece, lengthwise and cross moveable stage, coaxial focusing knobs (concerning fine drive: 200 µm / full turn), adjustment of eye relief, diopter adjustment and the phototube. Optional available, general accessories are the wide field eyepieces (WF10x, WF15x), the dividing eyepiece (WF10x), and dark field condensers (dry and oil).
_x000D_
_x000D_ FEATURES
_x000D_
- _x000D_
- Type: biology Microscope _x000D_
- View: Trinocular _x000D_
- Application range: Biology, Gemology, Botany, Education, Teaching, Entomology, Forensic, Research, Laboratory, Medical science, Pathology, Veterinary medicine _x000D_
- Illumination: LED
- Level: Intermediate, Expert _x000D_
- Warranty: 2 years _x000D_
- 1.25 Abbe-condenser with iris diaphragm and filter holder _x000D_
- Incl. adjustable mechanical stage _x000D_
- Integr. dimmer _x000D_
- Adjustable eye relief _x000D_
- Diopter adjustment _x000D_
_x000D_
- _x000D_
- Microscope _x000D_
- 4 DIN-objectives (PL 4x, PL 10x, PL 100x oil, PL-FL 40x)
- 2x 10x eyepieces _x000D_
- 1.25 Abbe-condenser with iris diaphragm and filter holder _x000D_
- Fluorescence attachment with LED wheel (green, blue, violett, ultraviolett) and respective emission filters
- Immersion oil _x000D_
- Full Koehler illumination for transmitted light _x000D_
