SWIT BM-U245HDR 23.8" 8K 4x12GSDI HDR

English description below

• 23.8-inch LCD Panel, 3840×2160 opløsning
• 1000nits høj lys LED-baggrundsbelysning
• HLG/PQ/S-log3 HDR, automatisk indstilling af nyttelast-ID
• 12GSDI 4-in 4-out, 8K input klar, HDMI2.0 input
• ST2110 IP via SFP Fiber input (valgfrit)

BM-U245HDR anvender et 23.8-inch 10-bit LCD panel, UHD 3840×2160 opløsning, 1000nits LED-baggrundsbelysning, 1000:1 kontrast, 91.9% DCI-P3 og 89% Rec2020 farveskala. Synsvinklen er H178° / V178°. Understøtter Supports Single link 4K input inklusiv 12GSDI, HDMI2.0 eller 12GSDI via SFP, og Quad link 4x 3GSDI 4K eller Quad link 4x 12GSDI 8K inputs. Du kan også indlæse 4x uafhængige 4K videoer til multiview, understøtter 12G/6G/3G/HD-SDI and HDMI 2.0/1.4/1.3 blandede formater input og bølgeform, vektor, lydmålere, EOTF, farveskala valg for hvert input. For mere information se foldere under fanen produktmedier nedenfor.

• 23.8-inch LCD Panel, 3840×2160 resolution
• 1000nits high bright LED backlight
• HLG/PQ/S-log3 HDR, Payload ID auto setting
• 12GSDI 4-in 4-out, 8K input ready, HDMI2.0 input
• ST2110 IP via SFP Fiber input (Optional)

BM-U245HDR adopts a 23.8-inch 10-bit LCD panel, UHD 3840×2160 resolution, 1000nits LED backlight, 1000:1 contrast, 91.9% DCI-P3 and 89% Rec2020 color gamut. The viewing angle is H178° / V178°.　Supports Single link 4K input including 12GSDI, HDMI2.0 or 12GSDI via SFP, and Quad link 4x 3GSDI 4K or Quad link 4x 12GSDI 8K inputs. You can also input 4x independent 4K videos to multiview, supports 12G/6G/3G/HD-SDI and HDMI 2.0/1.4/1.3 mixed formats input, and waveform, vector, audio meters, EOTF, color gamut selection for each input. More information, check leaflets under Product media tab below.
