SWIT PB-S146S 146Wh V-lock Cine

English description below

• Square shape design for Cine-cameras
• 146Wh, 10.1Ah larger capacity
• At least 200W, 16A constant high load
• 2× D-tap output sockets (120W/10A in total)
• 1× USB 5V/2A power output sockets

PB-S series camera batteries are compact designed, shorter than normal V/Gold mount batteries, and match perfectly with most of the Cine-cameras. Consists of 12pcs of high class 18650 battery cells, nominal voltage is 14.4V and reaches 146Wh / 10.1Ah high capacity. Can run approx 5 hours for normal 30W cameras. PB-S146S provides at least 200W/16A high load even at 1% capacity, to drive high power Cine cam- eras and on-camera devices together. The high load cells will also ensure battery life comparing to normal load batteries if long time full load output. Over current protection: 18A. PB-S146S provides 2x D-tap output sockets with 10A/120W load, and 1x USB 5V/2A socket, to power other on-camera devices together. The build-in LCD can displays remaining power percentage, remaining working time, low power warning, and battery cycle times, and support viewfinder info display on both SONY and RED cameras. Specifications Battery plate: V-mount Nominal voltage: 14.4V Capacity: 146Wh, 10.1Ah Max output In total: 200W Electrodes: 200W,16A USB:10W, 5V/2A D-tap: 120W / 10A Dimension: 121×95×59mm Charging Temperature: 0-40°C Discharging Temperature: -20°C-50°C（Capacity and Max Load may decrease when operating below 0°） Net weight: 0.878kg Max charging current: 5A D-TAP socket number: 2 USB socket number: 1
