English description below
- Optagelse i udsendelseskvalitet
- 1-sporet PCIe-slotkort (til 1-16 baner)
- SDI og HDMI indgange
- Op til 1080p60 opløsningsunderstøttelse i HDMI
- Mac, Windows, and Linux kompatibel
Få HDMI- og SDI-videooptagelse i udsendelseskvalitet til din PCIe-computer! DeckLink Mini Recorder HD har 3G-SDI og HDMI 2.0 til optagelse af SD- og HD-formater op til 1080p60 og 2Kp60 DCI! Du får et optagelseskort i udsendelseskvalitet, der er kompatibelt med stort set alt SD- og HD-udstyr og populær videosoftware såsom DaVinci Resolve og mere! Understøttede codecs AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, Apple ProRes 422 Proxy, ukomprimeret 8-bit 4:2:2, ukomprimeret 10-bit 4:2:2, ukomprimeret 10-bit 4:4:4. Software inkluderet Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility og Blackmagic driver på Mac OS og Windows. Media Express, Blackmagic Desktop Video Utility og Blackmagic driver på Linux. Intern softwareopgradering Firmware indbygget i software driver. Indlæses ved systemstart eller via opdateringssoftware. Fysisk Installation PCI Express 1 bane generation 2, kompatibel med 1, 4, 8 og 16 bane PCI Express slots på Mac OS, Windows og Linux. Mac OS-systemer kræver en Mac Pro-computer med PCI Express-slots. Tjek venligst supportsiderne for at se de fulde systemkrav. Andre understøttede applikationer inkluderer: Cinegy Capture Pro, DevTek EasyMediaSuite, Glookast Capturer, Livestream Producer, Metus Ingest, Softron MovieRecorder, ToolsOnAir just:in, Burst Video WebClip2Go & [REC]Marker, Zoom. Disse er tredjepartsapplikationer, og support kan variere, spørg din softwareleverandør. Specifikationer Videoindgange 1 x BNC (3G-SDI / HD-SDI / SD-SDI), 1 x HDMI (HDMI 2.0) Lydindgange Ingen Samtidig Multi-Input Support Ikke specificeret af producenten Input videoformat SDI (8/10/12-Bit 4:4:4 RGB) 1080p at 23.98/24/25/29.97/30 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps SDI (8/10-Bit 4:2:2 YUV) DCI 2K at 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2KPsF at 23.98/24/25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps HDMI (8-Bit 4:4:4 RGB, YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps HDMI (12-Bit 4:4:4 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps Indbygget lyd SDI: 16-Channel, HDMI: 8-Channel Standarder Videostandardoverholdelse SMPTE 259M/274M/296M/424M/425M-A/425M-B/ST-2108-1 HDR kompatibilitet Ikke specificeret af producenten Hardware OS kompatibilitet macOS 11.1 macOS 12.0 eller nyere Windows 10 Windows 11 Linux *Fra og med juli 2022: Spørg producenten for den mest opdaterede kompatibilitet Strømforbrug Enhed: 3 W Hvad er inkluderet DeckLink Mini Recorder HD Lavprofilspaltebeslag
- Broadcast-Quality Recording
- 1-Lane PCIe Slot Card (for 1-16 Lanes)
- SDI and HDMI Inputs
- Up to 1080p60 Resolution Support in HDMI
- Mac, Windows, and Linux Compatible
Get broadcast quality HDMI and SDI video capture for your PCIe computer! DeckLink Mini Recorder HD features 3G-SDI and HDMI 2.0 for recording SD and HD formats up to 1080p60 and 2Kp60 DCI! You get a broadcast quality capture card that’s compatible with virtually all SD and HD equipment and popular video software such as DaVinci Resolve and more! Supported Codecs AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4. Software Included Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux. Internal Software Upgrade Firmware built into software driver. Loaded at system start or via updater software. Physical Installation PCI Express 1 lane generation 2, compatible with 1, 4, 8 and 16 lane PCI Express slots on Mac OS, Windows and Linux. Mac OS systems require a Mac Pro computer with PCI Express slots. Please check the Support pages to see the full system requirements. Other supported applications include: Cinegy Capture Pro, DevTek EasyMediaSuite, Glookast Capturer, Livestream Producer, Metus Ingest, Softron MovieRecorder, ToolsOnAir just:in, Burst Video WebClip2Go & [REC]Marker, Zoom. These are third party applications and support may vary, check with your software vendor. Specifications Video Inputs 1 x BNC (3G-SDI / HD-SDI / SD-SDI), 1 x HDMI (HDMI 2.0) Audio Inputs None Simultaneous Multi-Input Support Not Specified by Manufacturer Input Video Format SDI (8/10/12-Bit 4:4:4 RGB) 1080p at 23.98/24/25/29.97/30 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps SDI (8/10-Bit 4:2:2 YUV) DCI 2K at 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2KPsF at 23.98/24/25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps HDMI (8-Bit 4:4:4 RGB, YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps HDMI (12-Bit 4:4:4 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps Embedded Audio SDI: 16-Channel, HDMI: 8-Channel Standards Video Standard Compliance SMPTE 259M/274M/296M/424M/425M-A/425M-B/ST-2108-1 HDR Compatibility Not Specified by Manufacturer Hardware OS Compatibility macOS 11.1 macOS 12.0 or Later Windows 10 Windows 11 Linux *As of July, 2022: Check with manufacturer for the most up-to-date compatibility Power Consumption Device: 3 W What´s Included DeckLink Mini Recorder HD Low profile slot bracket
